Island Packet 350
Contact Seller
XPresented For Sale By:
S&J Yachts
United States
| Make | Island Packet |
|---|---|
| Model | 350 |
| Year | 2000 |
| Condition | Used |
| Price | US$130,000 |
| Type | Sail |
| Class | Cruiser |
| Length | 11.23 m |
| Fuel Type | Diesel |
| Hull Material | Fibreglass |
| Location | Rock Hall, Maryland, United States |
| LOA | 11.23 m |
|---|---|
| Length at Water Line | 8.94 m |
| Beam | 3.66 m |
| Max Draft | 1.3 m |
| Keel Type | enums.keel-type.kt-full |
| Displacement | 16000 lb |
| Ballast | 7500 lb |
| Dry Weight | 16000 lb |
| Cabin Headroom | 1.93 m |
| Engine Type | Inboard |
|---|---|
| Engine Make | Yanmar 3JHE |
| Engine Model | Yanmar 3JHE |
| Fuel Type | Diesel |
| Engine Year | 2000 |
| Power | 38 hp |
| Drive Type | Direct Drive |
| Engine Location | enums.engine-location.center |
| Propeller Type | 3 Blade |
| Propeller Material | Bronze |
| Engine usage (hours) | 4311 |
| Designer | Robert K. Johnson |
|---|---|
| Builder | Island Packet |
| Guest Cabins | 2 |
| Guest Heads | 1 |
| Fuel Tanks | 50 gal |
| Fresh Water Tanks | 100 gal |
| Hull Shape | Monohull |
| Hull Warranty | None |
Description
WALK-THRU
As you step below you are greeted by a large open salon, due to the fact that the table is folded up against the forward bulkhead. When the table is open it reveals bottle rack and small item storage. This table folds down with a large leaf that folds over to provide seating from both the port and starboard settee. The L-shaped settee to starboard pulls out to make a double berth with the port side being a single, with this added sleeping capacity providing sleeping for (7). The settees are covered in an off-white ultra leather fabric (condition is like new). There is large amounts of storage both behind and beneath both settees. Both natural light and ventilation is provided by (4) opening ports and a large overhead hatch. For added security when underway there are (2) overhead teak handrails.
To starboard at the aft end of the salon is an aft facing nav station with chart table and all breaker panels for both 12 volt and 120 volt are located here, electronics as well.
The gallery is located just aft of the salon and to starboard at the base of the companionway. This is a large u-shaped area with countertops covered with an off white Formica and solid teak sea rails on all open edges. There is a large 14 cubic foot, top load ice box / refrigerator with lift out shelf as well as an electric sump drain. There is a two burner LPG gimbled stainless steel stove with oven for cooking and for clean up a large double bowl stainless steel sink. Hot and cold pressure water as well as a cold water hand pump. Tip out trash bin for those unwanted items. Plenty of storage both above and below the counter includes a designated dish rack and cutlery drawers.
Access to the aft cabin is to the port side of the the companionway. Large double berth with a full-length teak shelf outboard, stowage lockers beneath. A large cedar lined hanging locker, bureau w/shelf-over, two opening ports and a small overhead hatch.
The head is located just forward of the salon and to starboard. This space has a vanity with storage beneath, with a contoured counter top so there are no sharp corners, off white counter top with teak fiddle and a stainless steel sink. The toilet is centrally located and is an electric Eco-Vac unit by Sealand. Next to the head is a dedicated teak shower seat.
For the owner’s stateroom located just forward of the head. There is a pullman style berth to starboard, a small seat and a full-length shelf outboard on both port and starboard of the cabin. To port is a bureau containing shelved storage and a large cedar lined hanging locker. There are three opening ports as well as a large overhead hatch.
This cabin has it's private access door to the head.
Engine access is very good with large removeable teak box that is located beneath the companionway stairs providing access to the front end of the engine. Beneath the aft berth are removable panels to access the aft end of the engine as well as the shaft and stuffing box.
The entire yacht is beautifully finished teak through-out with teak and holy cabin sole except for at the base of the companionway, galley and head which have a diamond patterned molded fiberglass.
This 350 doesn't differ from the rest of the Island Packet line in that she has the time proven trade mark "Full Foil Keel". This provides for a moderate draft for her size enabling the owner expanded cruising ground access, integrated one piece hull and keel providing for stronger construction and the airfoil shape provides better upwind performance with a modern hull shape providing enhanced boat speed and maneuverability. The transom has an integrally molded in swim platform. The hull is 100% hand laid triaxial woven fiber glass, using NO coring material. The deck is constructed using PolyCore which is a microsphere and resin matrix.
The large cockpit has to 7 1/2 foot contoured seats and separate raised helm seat with padded back rest. Storage provided by two large lockers and a separate insulated cockpit icebox. Deck is two tone with molded diamond patterned slip resistant surface. Side decks are wide have a raised bulwarks that increase in height as you move forward. Starboard side deck has a molded propane locker with storage space for 2 tanks. Access to the anchor locker is provided through a Lewmar hatch.
DECK and HULL
- 100% Hand Laid Fiberglass Throughout with ISO/NPG Type Gel Coat
- One Piece Molded Hull Including Keel (Triaxial Woven Glass)
- Deck Cored with Polycel” (Microsphere and Resin Mixture)
- Bow Pulpit (Double Stainless Steel)
- Stern Rail (Split Double Stainless Steel with Integral Seats)
- Lifelines with Boarding Gates Port and Starboard
- Stern Gate
- Swim Ladder (Folding Stainless Steel)
- Double Anchor rollers on Anchor Platform
- Anchor Windlass (Lofrans Electric, Controls at Bow and Cockpit)
- Deck Cleats (2 -12" Bow, 2-12" Stern, 2-10 Spring)
- Pedestal with Stainless Steel Guard, Compass, Instruments and GPS
- Whitlock Rack & Pinion Steering with Stainless Steel Destroyer Wheel and Wheel Brake
- Emergency Tiller
- Davits (Folding by Kato Marine with Stainless Support Straps and Spreader Bar)
- Outboard Motor Lift (Garhauer)
- Cockpit Table (Folding)
- Ports (11 Opening Stainless Steel)
- Hatches (5 Lewmar)
- Dorades (3 Stainless Steel with Guards)
COCKPIT
- VHF (Standard Horizon Matrix AIS + GX 2150)
- Knot Meter (B&G Network Pod, Mounted at Helm)
- Depth Sounder (B&G Network, Pod Mounted at Helm)
- Wind (B&G Network, Pod Mounted at Helm)
- Autopilot (Garmin GHC 20 Control Head)
- Autopilot (Below Deck Electric Ram)
- Compass (Richie Powerdamp)
- Chartplotter (Garmin GPSmap 546)
- Radar (Furuno 36 Mile Bulkhead Mounted, Dome Mounted on Questas Gimbaled Back Stay Mount)
- I-Pad Mount on Pedestal
NAV STATION
- VHF (Standard Horizon GX2000)
- SSB (ICOM IC-M710 with ICOM AT-130 Automatic Antenna Tuner, Insulated Backstay and Grounding Plate)
- Network Data Repeater (B&G Network)
- Chartplotter (Garmin 176C)
- Stereo (Alpine Stereo / CD Player, Speakers Inside and Out)
12 Volt
- Main Disconnect Switch
- Breaker Panel with Volt and Amp Meters
- Battery Monitor (Bogart Engineering Tri-Metric TM-2030-A
- Battery Test Switch
- Engine Hour Meter
- Propane Solenoid
- Refrigeration (Frigoboat with Keel Cooled Compressor)
- Bilge Pump
- Fresh Water Pump
- Shower/ Icebox Sump Pump
- Running Lights
- Steaming Light
- Anchor Light
- Foredeck Light
- Interior Lights
- Courtesy Lights
- Battery Monitor (Zantrex Link 2000-R)
- Windlass (Lofrans)
- LPG Remote Solenoid
- Batteries (6 - Group 31 AGM's)
- Alternator (Balmar 110 amp High Output)
- Fans
120 Volt
- (2) 30 amp Power Inlets with Cover
- (2) 50' - 30 amp Power Cords
- (2) 30 amp Main Breakers at Inlets
- 120 V. Breaker Panel with Volt Meter
- Water Heater (6 Gallon)
- Battery Charger ( )
- (6) 120V. GFI Protected Outlets
- Microwave Oven (Origo)
- Air Conditioning and Heat (Marine Air 16,000 BTY)
- Hot and Cold Fresh Water System
- Cold Water Cockpit Shower
- Fresh Water Pump (Electric)
- Fresh Water Cold Water Pump (Manual Hand)
- Marine Head (Electric , EcoVac by Sealand)
- Fresh Water Tank (100 Gallon, Welded Aluminum)
- Holding Tank (30 Gallon, Replaced with Fiberglass, Y-Valve)
- Fuel Tank (50 Gallon Welded Aluminum)
- Bilge Pump (Electric)
- Bilge Pump (Manual)
- Propane Aluminum Tank and Plumbing to Stove
- Mast (Keel Stepped Anodized Aluminum)
- Boom Anodized Aluminum with Internal Single Line Reefing
- Single Spreader
- Full Double Back Stay
- Dutchman
- Boom Vang
- Head Sail Furler (Harken)
- Staysail Furler (Harken)
- Staysail Hoyt Boom (Anodized Aluminum)
- Winches (Primary 2 - Lewmar 44 CST's 2-speed)
- Winch (Main Sheet & Main Halyard 1 - Lewmar 40 CST)
- Winch (Main, Single Line Reefing 1 - Lewmar 30 CST
- Winch (Jib Halyard on Mast - Lewmar 16C 2-speed)
- Winch Handles
- Main Sheet Traveler Mounted Forward of Dodger
- Main Sheet Mid-Boom Sheeting
- Genoa Tracks and Cars Mounted On Cap Rail
- Mainsail (Full Batten with Dutchman System and Single Line Reefing)
- Genoa (130% Furling)
- Staysail (Furling, on Self Tacking Hoyt Boom)
- Dodger (Sunbrella with Stainless Steel Side and Aft Grab Rails)
- Bimini (Sunbrella)
- Connecting Panel (Sunbrella)
- Cockpit Cushions (Sunbrella with 4" Foam)
- Full Winter Cover
Sail Area
IJPE : 615.83 sq ft
I : 44.83 ft
J : 15.67 ft
P : 37.00 ft
E : 14.25 ft
Factory Equipment List
Island Packet 320 Specifications - Standard Equipment Rig - Sails - Hardware - Sails: Main w- double reef, 130 percent roller furling genoa, roller furling staysail - premium high modulus Dacron - Sobstad - Mainsail cover, genoa & staysail sun panels in choice of Sunbrella colors - Genoa gear, including tracks, blocks, sheets and Harken furling system - Staysail gear including blocks, halyard, sheet, Harken furling system and Hoyt self-vanging boom - Jib halyard winch on mast, Lewmar 16C 2-speed - Main halyard (on roller bearing masthead sheave) and main sheet, led to cockpit through stoppers to Lewmar 30 STC winch - Dual single line "Auto Reefing" system for double set of reef points led to cockpit through stoppers to Lewmar 30 STC winch - All halyards internal; color coded running rigging, convenient coaming storage bins for lines - Boom vang - preventer package - Winch handle - 10" lock-in chrome - Jib sheet winches (2) Lewmar 40 STC 2-speed - Midboom sheeting for unobstructed cockpit & dodger installations - Main sheet traveler w- 4:1 control system led to cockpit - Wheel steering - console mounted Whitlock "Premier XL" rack & pinion direct system with wheel brake, stainless steel wheel. Guard, single lever engine control. Emergency tiller with storage brackets in sail locker - Compass: Ritchie with custom Island Packet nav grid - Welded stainless steel double bow rail & stern rail, stanchions, stern rail with twin seats, stainless steel flagstaff & holder - Double lifelines, full-length stainless steel cabin top hand rails - Hinged padeyes (4) for cockpit harness attachment - Stern gate w- quick release hook - Swim ladder - stainless steel transom mount w- rubber treads - Two stainless steel anchor rollers w- chocks and hinged deck pipes to forepeak - Four 10" mooring cleats, two 10" spring line cleats, chocks & stainless steel chafe guards - Twin backstays for easy stern boarding & unobstructed helm seating - Topping lift-adjustable - Keel stepped mast, all anodized spars Interior - Nine opening ports w- screens - polished stainless steel, safety glass - Six deck hatches - forward cabin, salon (2), head, aft cabin, galley - Lewmar (acrylic & aluminum) - Three deck ventilators (dorade type) w- screens - Large forepeak w- louvered access door & overhead deck pipes, light, drain to bilge, center divider w- attachment for rodes - Forward cabin w- privacy door to salon. Large double Pullman berth w- teak shelves outboard, stowage under. Cedar lined hanging locker w- shelf over, bureau w- shelf over. Two opening ports plus overhead hatch, deck vent, varnished teak & holly sole - Forward head w- shower (electric drain pump), teak trim, curtain on track, large vanity with polished stainless steel sink, teak shower seat, storage cabinets, opening port & an overhead hatch, toothbrush holder w- cup, toilet paper holder, integral recessed lighting - Main salon w- L-shaped pullout double settee berth to port, single settee berth to starboard, teak cabinets & bookshelves outboard of both settees. Large stowage areas behind & under each settee. Deluxe drop leaf table folds against bulkhead rack (w- bottle stowage) for unobstructed 4' wide varnished teak & holly sole. Two overhead hatches, numerous opening ports, deck vents & overhead hand rails - Chart stowage drawer beneath port settee - Hinged navigation station table at forward end of aft cabin, Nav light, nav - electronics cabinet w- master AC-DC electrical panel plus room for owner installed equipment - Aft cabin w- bi-fold door to main cabin and hinged nav table - privacy panel for either open or private configuration. Large athwartship double berth w- teak shelf outboard, integral overhead reading lights, stowage under. Cedar lined hanging locker w- shelf over, bureau w- shelf over, opening port, overhead hatch, varnished teak & holly sole - Courtesy - night lights with switch by companionway - All interior cushions of upholstery grade foam covered in premium designer fabric - Removable teak companionway ladder w- engine access from all sides - Storage rack for companionway drop boards - Molded slip resistant cabin sole adjacent to companionway, and galley, w- draining grate in front of ladder. Teak grate lifts out for dust pan, dust pan lifts for bilge sump access with light - Teak bulkheads, cabinetry, trim - select grain w- hand-rubbed oil finish - Teak louvered cabin & locker doors - deluxe trim; push button safety latches on locker doors - Molded fiberglass interior headliner w- textured finish, teak trim - Teak & holly sole in main salon, forward & aft cabins - varnish finish Galley - Large U-shaped design w- Formica surfaces, teak sea rails on all edges - Icebox - top loading, superior injected froth type urethane insulation throughout, lift-out shelf, large 10 cubic foot volume, electric drain pump, inside light w- manual switch - Gimbaled two-burner LPG stove w- oven - stainless steel deluxe safety type, liftoff cover, stainless steel guardrail w- harness hooks. Pot and pan locker under - Double stainless steel sink with deluxe polished finish, hot & cold pressure water tap, manual pump, retractable spray unit - Rollaway trash bin, teak paper towel holder & soap rack - Deluxe teak dish rack & cutlery drawers - Large storage areas above & below counter, microwave alcove, two large drawers beneath icebox - Cockpit instrument access cabinet - Flip up counter extension Exterior - Construction - 100% hand-laid high modulus fiberglass construction throughout with special gelcoats for durability; Island Packet's exclusive PolyClad hull gelcoat system with 10-year limited warranty for osmotic blisters. All gelcoats applied using premium high-volume, low-pressure application equipment for exceptional finish quality, reduced airborne emissions - All structural laminates and reinforcements designed to meet or exceed ABS standards - Hull molded in one piece utilizing a proprietary pressure fed application system w- premium high modulus triaxial glass, unified w- an engineered molded interior grid structure - Deck laminate cored w- advanced PolyCore - a proprietary microsphere & resin matrix with 10-year limited warranty for rot and delamination (an industry first) - Exclusive Durashield deck gelcoat system with superior gloss retention and resistance to fading and crazing - Deck attached to integrally molded hull flange w- bolts, lock nuts, & urethane adhesive sealant - Deck hardware thru-bolted w- aluminum backup plates - Two-tone deck, low-glare light ivory with integrally molded light tan slip resistant surface (premium coarse diamond pattern) - Light ivory hull w- gold cove (or optional rigid vinyl rub rail w- s.s... striker) & choice of boot stripe color - Teak cap rail w- stainless steel striker, teak cap on bowsprit - Deluxe helm console with guard - handgrip, compass, single-lever engine control - Contoured cockpit seats, coaming storage boxes and bins, seat hatches with push-button latches with locks, molded helm seat with teak top, cushion and backrest. Two stern rail seats - Molded fiberglass sliding companionway hatch w- sea hood, latch inside, exterior hasp and lock - Companionway drop boards of solid teak, center drop board fitted with fixed port with etched logo (safety glass), captive safety lock-in pin with holder, interior storage rack - All exterior teak treated with Sikkens Cetol teak finish - Two 2" cockpit scuppers - Cockpit ice box - foam insulation, hinged lid - Fresh water cockpit shower - wash down (cold only) - LPG deck storage bin with 10 lb. aluminum propane tank (plus room for spare), drain overboard Mechanical - Electrical - Plumbing - 27 hp Yanmar 3GM30 diesel - three cylinder, fresh water cooled, rubber isolation mounts on reinforced fiberglass bed with integral oil drip pan, twin fuel pumps (mechanical and electrical), twin fuel filters, 3-blade prop - Racor fuel filter with water separator, jacketed fuel line w- swedged ends - Extensive sound control in engine compartment with premium lead lined foam insulation - Engine intake strainer - bronze, easy access, w- bilge light - Recessed cockpit instrument panel w- electric tachometer, engine monitoring gauges & warning system - removable acrylic cover - Single-lever engine control mounted on pedestal - Two premium AGM (absorbed glass mat) sealed 12 volt batteries - Group 27. Stainless steel hold down bar, room for additional batteries. - Deluxe electric panels w- four-way battery switch, circuit breakers for DC & AC systems, DC & AC gauges, battery test system, reverse polarity protection, indicator lights, elec. pump controls, LPG control, battery charger control - AC 30 amp dockside power system w- inlet breaker, polarity protection, 50' shorepower cord, numerous interior outlets w- GFI protection, galvanic isolator - Marine converter - battery charger - 30 amp Raritan B-series - Numerous 12V interior lamps and (3) courtesy lamps with rocker switch at companionway; dome lights in cockpit lockers, forepeak, icebox, bilge, engine area - Water heater - 6 gallon marine type w- engine heat exchanger & AC operation, UL approved, foam jacketed hot water hoses - Pressure water system w- hot & cold water tap in galley & head, shower in head, cockpit (cold only) - Manual water pump in galley - LPG stove system w- 10 lb. aluminum tank (in draining deck storage well), remote solenoid shutoff, gauge - Marine head (Raritan), with premium triple walled sanitation hose, direct overboard discharge or bypass valve into holding tank. Water intake to heads protected by bronze strainer - 26 gallon (US) welded marine aluminum holding tank w- sealed interior, deck pump out fitting - 90 gallon (US) welded marine aluminum fresh water tank w- deck fill, remote gauge - 45 gallon (US) welded marine aluminum fuel tank w- shutoff valve, deck fill, remote gauge. Pre-plumbed for additional pickup - return - Fuel, water and holding tankage below cabin sole maximizing storage space & minimizing trim changes - Deck fittings for water, fuel, waste - stainless steel w- deck key - Electric bilge pump w- auto switch integral w- master panel, premium Ultimate magnetic reed float switch - Manual bilge pump - heavy duty (1 1-2" hose). Mounted in cockpit near helm - Shower drain pump - electric w- switch - Icebox drain pump - electric w- switch - UL approved bronze thru-bolted flanged seacocks on all thru-hulls below waterline; ball valves on all thru-hulls in boot stripe - Electrical bonding system for rig and underwater metals - UL approved marine, pretinned color coded wiring - Foredeck light-mast mounted - Masthead anchor light, nav lights - Prewired: VHF antenna cable in mast & interior; fan wires throughout interior; refrigeration wire, speaker wires - Messenger pre-run for cabin back mounted electronics Island Packet 320 Optional Equipment - Fully-battened main (in lieu of standard) with Battslides - Roller furling mast (in lieu of standard) with spare halyard - Cockpit cushions (4 pc) - 2" closed cell foam - Microwave oven - Rub rail - co-extruded hi-impact vinyl molded in hull color, w- s.s.. striker
Disclaimer
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
